Liquid Version Related Machines

Liquid Photopolymer Plate Making & Drying Machine

Liquid plate washing drying machine
Liquid Photopolymer Plate Making
Flexo Polymer Plate Printing
Description:
INQUIRY EMAIL

Model	Tengjun 4260	Tengjun 5280
Plate type	Liquid photopolymer resin plate	Liquid photopolymer resin plate
Plate size(MAX)	1600x1100	1320x2032mm
Brush	Good quality nylon bristle	Good quality nylon bristle
Plate thickness	2mm ~ 7mm	2mm ~ 7mm
Drying layer	2	2
Power supply	7.5kW 3P+N+PE, 380~415VAC	7.5kW 3P+N+PE, 380~415VAC
Dimensions (LxWxH)	22001600850 mm	26001800850 mm
Weight, equipment	850KG	1050KG

Comparison of Product Market Value:

1. With installed of micro-programmed control system (PLC), synchronized with HMI touch screen control panel, simplified plate
making process, improved process timing accuracy; as compare to conventional type of processing switcher control, PLC with HMI
Touch Screen having longer durability performance & more stable in light exposure, assure in product
2. In-order to produce high quality printing plate, imported Upper & lower glass been processed grinding to a very tight
tolerance, contact surface gap kept below ±0.05mm.
3. All consumable electrical parts with imported Schneider brand, and all motors is product of Taiwan, this to assure plate
making system consistent
4. Movement of upper light compartment is speedy controlled by high precision bilateral screw track bar，and high wear-resistant
copper nuts, at least 10 years operating life.
5. Upper & Lower light compartment installed with high quality exhaust fan, it maintain constant UV light intensity, prolong UV
lamps life span; easy access to wiring & UV lamp, convenient for inspection, maintenance and parts

1． All UV lamps using imported brand of Philips and Hitachi; Phillip 3AAA UV light ballast ensure stable in UV light source.
2． Vacuum pump and air compressor installed inside main exposure unit, user do not require addition purchase.
3． Exterior body of Post exposure unit powder coated with stainless steel frame work, prevent from rust & corrosion. 4． Product
sold beside China, our business cover South East Asia and Africa.

We are committed to reform and innovation, adapt to market demand, whether traditional or digital edition producers can produce high-quality flexible edition through our equipment.
